Burnhamia: an Eocene ray with crushing teeth

A rare jaw fossil, CT evidence and a cautious interpretation of feeding evolution.

Burnhamia daviesi reconstructed as an Eocene ray in coastal water
The fossil preserves teeth and parts of the jaws; the ray’s complete body and colour are reconstructed from comparison.

Burnhamia is an early Eocene ray known from an unusually informative, though incomplete, type fossil. Teeth and parts of the jaw cartilages were preserved together in a concretion from the Isle of Sheppey. CT imaging made their arrangement visible without removing them from the surrounding rock. The specimen supports comparisons about ray feeding anatomy; it does not preserve a complete animal or a direct record of its meals.

Type speciesBurnhamia daviesi
GroupEarly Eocene ray, generally placed among myliobatiforms
Type localityIsle of Sheppey, London Clay, England
Type specimenNHMUK P.1514; teeth and portions of the upper and lower jaw cartilages
Best-studied methodComputed tomography of the fossil in its concretion
Body sizeUnknown; no complete skeleton or reliable total-length estimate
Evidence guide

What the fossil can tell us

NHMUK P.1514 preserves teeth with parts of both jaws

The specimen came from the London Clay of Sheppey and remains incomplete inside its concretion. The surviving cartilage and tooth rows allow anatomical comparison, but do not supply a full skeleton or soft tissues.

A name based on teeth, then a rare jaw fossil

Arthur Smith Woodward described the species in 1889 under the name Rhinoptera daviesii. Later work transferred it to Burnhamia. That change followed comparisons of fossil teeth, not the discovery of a complete skeleton. The type specimen NHMUK P.1514 is especially useful because it preserves more than an isolated tooth: parts of the upper and lower jaw cartilages occur with the dentition.

The material came from the London Clay on the Isle of Sheppey, a marine deposit of early Eocene age. Most of the fossil is enclosed in a phosphate concretion. Its surviving sections include part of Meckel’s cartilage and the pterygoquadrate cartilage, but the front joint between the lower jaws and outer parts of the apparatus are missing.

What CT imaging revealed

The hard matrix makes the structures difficult to inspect from the surface. A 2017 study used computed tomography to distinguish the fossil material from the surrounding concretion and examine the teeth in place. The scans let researchers compare the arrangement of the preserved jaw elements without mechanically extracting them. This method reveals hidden anatomy, but it cannot recover structures that never fossilised or were lost.

Broad teeth form a multirow crushing surface. Their position and shape can be compared with dentitions in other rays, including Coupatezia, whose fossil record is mostly isolated teeth. Such comparisons help test relationships and feeding mechanics, while keeping the very different preservation of each genus in view.

Feeding anatomy and the limits of the plankton hypothesis

The CT study placed the dental pattern in a broader account of how some rays evolved toward feeding on small suspended prey. The authors interpreted a combination of dental features as relevant to that transition. This is an evolutionary inference from anatomy, not evidence that the fossil had the complete filtering system of a modern manta or that plankton made up its entire diet.

No gill rakers, cephalic lobes or soft filtering tissues are preserved. Nor is there stomach content identifying a meal. The London Clay records a marine burial setting, not the exact depth or feeding behaviour of this individual. The teeth show a broad processing surface; more specific claims about prey remain hypotheses.

Tooth variation and taxonomic caution

Some teeth have folds or small projections that differ from the broader crushing forms. The study compared these features with sexual heterodonty in living mobulid rays and proposed that they might reflect differences between males and females. Fossil sex is not directly observable here. Position in the jaw, age and differences between species can also affect tooth shape, so the proposed explanation remains tentative.

A second named species, Burnhamia fetahi, has been distinguished by narrower, lower-crowned teeth. Isolated plates from separate localities should not automatically be assigned to the type species. Crown and root form, age, locality and preservation all matter, and a genus-level resemblance does not make distant finds one population.

The ray beyond the preserved jaws

No complete skeleton establishes the disc diameter, total length, tail, fins, skin or colour of Burnhamia. A ray-like body in an illustration is a comparative reconstruction based on related batoids. It should not be read as a measured portrait of NHMUK P.1514 or as evidence for a particular swimming style.

The strongest account begins with the specimen itself: an early Eocene ray whose teeth and jaw cartilage can be examined together with CT. Its importance for the evolution of planktivory comes from how those structures compare with other rays. The fossil supports that question without resolving every detail of diet or life history.

Frequently asked questions

What fossil is known for Burnhamia?

The type specimen NHMUK P.1514 preserves teeth and parts of the upper and lower jaw cartilages from the London Clay of the Isle of Sheppey. It is incomplete and does not preserve a full body.

How did CT scanning help study the fossil?

Computed tomography revealed the arrangement of teeth and jaw structures within the concretion without mechanically extracting the fossil. It cannot restore missing anatomy.

Was Burnhamia a filter feeder like a manta ray?

Researchers interpreted its dental anatomy as relevant to the evolution of planktivory, but the specimen lacks the soft filtering structures of living manta rays. Its exact diet is not known.

Do unusual teeth prove the sex of fossil individuals?

No. A sexual explanation has been proposed by comparison with living mobulids, but fossil sex is not directly observed and other sources of tooth variation remain possible.
